3.0 Liter
Industrial
| PRODUCT SPECIFICATIONS | |
| Model Number | 3.0L |
|---|---|
| Cylinders | I-4 |
| Combustion System | Spark-ignited |
| Cooling System | Water-cooled |
| Displacement | 181 cid (2,966.6 cc) |
| Compression Ratio | 8:2:1 |
| Bore & Stroke | 4.00 in x 3.60 in (101.5 mm x 91.4 mm) |
| Fuel Type | GASOLINE, PROPANE (LP) |
| Direction of rotation | Counter-clockwise viewed on flywheel |
SAE J1995 rated following 36300018 PSI Derate Specification with a tolerance of +/-5%. Power and torque values are based on standard assumptions. kWe values are based on standard assumptions for mechanical and electrical losses. Ratings and performance are solely for reference only and subject to site conditions and PSI application and ratings guidelines. The product images shown are for illustration purposes only and may not be an exact representation of the final product. All information is subject to change without notice.
POWER RATINGS
GENERAL DATA & FEATURES
DIMENSIONS
| PEAK POWER AND TORQUE | ||||
| Fuel | HP | KW | LB-FT | NM |
|---|---|---|---|---|
| Gasoline – High Profile | 80.5 | 60.0 | 141.5 | 191.8 |
| Gasoline – Low Profile | 76.4 | 57.0 | 142.4 | 193.1 |
| Propane | 80.5 | 60.0 | 147.5 | 200.0 |
- Fuel options: LPG, gasoline, bi-fuel
- Sequential Electronic Fuel Injection (SEFI) for gasoline
- Fuel and emission control system that meets Tier II
- EPA/CARB emission regulations for LSI engines
- SAE flywheel housings and flywheels
- Additional crankshaft pulleys
- Cooling fans
- Radiator
- Electronic governors
- Remote oil filter and auxiliary oil drain
- 95A alternator option / 70A alternator standard
- High silicon content pistons for improved durability and noise reduction
- Sintered powdered-metal exhaust valve seat inserts for enhanced durability
- World-class engine sealing system for superior leak protection
- Integral harmonic balancer/crankshaft pulley for easier accessory drive dress
- Intake/exhaust manifolds standard
- Common rear face to GM Powertrain industrial engines for easy hookup with housing
- Emission Certified with U.S. EPA and CARB – Industrial Mobile
| DIMENSIONS | IN | MM |
| Length | 25.16 | 639.1 |
| Width | 20.14 | 511.6 |
| Height | 28.45 | 722.6 |
