5.7 Liter
Industrial
| PRODUCT SPECIFICATIONS | |
| Model Number | 5.7L |
|---|---|
| Cylinders | V-8 |
| Combustion System | Spark-ignited |
| Cooling System | Water-cooled |
| Displacement | 350 cid (5,736.5 cc) |
| Compression Ratio | 9.4:1 |
| Bore & Stroke | 4.00 in x 3.48 in (101.6 mm x 88.4 mm) |
| Fuel Type | GASOLINE |
| Direction of rotation | Counter-clockwise viewed on flywheel |
SAE J1995 rated following 36300018 PSI Derate Specification with a tolerance of +/-5%. Power and torque values are based on standard assumptions. kWe values are based on standard assumptions for mechanical and electrical losses. Ratings and performance are solely for reference only and subject to site conditions and PSI application and ratings guidelines. The product images shown are for illustration purposes only and may not be an exact representation of the final product. All information is subject to change without notice.
POWER RATINGS
GENERAL DATA & FEATURES
DIMENSIONS
| PEAK POWER AND TORQUE | ||||
| Fuel | HP | KW | LB-FT | NM |
|---|---|---|---|---|
| Gasoline | 179.8 | 134.1 | 316 | 428.4 |
| LPG | 133.2 | 99.3 | 305.6 | 414.3 |
- Fuel and emission control system that meets Tier II EPA/CARB emission regulations for LSI engines
- SAE flywheel housings and flywheels
- Custom-made flywheels for numerous applications
- Auxiliary drive pulleys available
- Cooling fans
- Radiator
- Dry-type industrial air cleaners (safety element available)
- Electronic governors
- Remote oil filter
- Auxiliary oil drain
- Metal engine skid
- 95A alternator option / 70A alternator standard
| DIMENSIONS | IN | MM |
| Length | 30.36 | 771.1 |
| Width | 23.74 | 603.0 |
| Height | 33.71 | 856.2 |
