53 Liter

,
Model Number 53 Liter
Combustion System Spark-ignited
Cooling System Water-cooled
Displacement 3,192 cid (52,308 cc)
Compression Ratio 10.5:1
Bore & Stroke 5.91 in x 7.28 in (150 mm x 185 mm)
Fuel Type NATURAL GAS (NG), PROPANE (LP)
Direction of Rotation Counter-clockwise viewed on flywheel
SAE J1995 rated following PASI Specification with a tolerance of +/-5%. Power and torque values are based on standard assumptions. kWe values are based on standard assumptions for mechanical and electrical losses. Ratings and performance are solely for reference only and subject to site conditions and PSI application and ratings guidelines. The product images shown are for illustration purposes only and may not be an exact representation of the final product. All information is subject to change without notice.
50 Hz (1500 RPM)
Rating Fuel kWe kWm bHp
Standby NG 870 987 1324
Standby LP 655 744 998
LTP NG 870 987 1324
LTP LPG 655 744 998
Prime NG 780 888 1191
Prime LPG 590 670 898
60 Hz (1800 RPM)
Rating Fuel kWe kWm bHp
Standby HO NG 1250 1436 1924
Standby NG 1050 1185 1589
Standby LPG 785 892 1196
LTP NG 1050 1185 1589
LTP LPG 785 892 1196
Prime NG 925 1067 1431
Prime LPG 705 803 1077
  • Turbo-charged and after cooled, cast iron with wet cylinder liners v-block
  • Cast iron cylinder block with inspection door per cylinder
  • Modular four-valve cast iron cylinder heads
  • Weichai supplied engine block
  • High strength alloy steel forged crankshaft
  • Thermostatically-controlled cooling system with engine integrated oil cooler
  • Gear driven dual water pump and engine mounted fan
  • J1939 CANBUS interface
  • 3-Way Catalyst
  • High efficiency air filter
  • SAE #0 flywheel housing, SAE #18 flywheel
  • Proven US ECU, fuel system and engine control
  • U.S. EPA-Certified 2019
  • Oil cooled light alloy pistons with high performance piston rings
  • Hardened valves and valve seats
  • Valley mounted water cooled exhaust manifold
  • Telematics compatibility
  • Full flow oil filter
DIMENSIONS IN MM
Length 113.7 2,888
Width 68.0 1,1727
Height 70.2 1,783
