1.0 Liter

Model Number	1.0 Liter
Cylinders	4
Combustion System	Spark-ignited
Cooling System	Water-cooled
Displacement	60.9 cid (998 cc)
Compression Ratio	9.5:1
Bore & Stroke	2.57 in x 2.83 in (65.5 mm x 72.0 mm)
Fuel Type	GASOLINE, PROPANE (LP)
Direction of Rotation	Counter-clockwise viewed on flywheel

SAE J1995 rated following PASI Specification with a tolerance of +/-5%. Power and torque values are based on standard assumptions. kWe values are based on standard assumptions for mechanical and electrical losses. Ratings and performance are solely for reference only and subject to site conditions and PSI application and ratings guidelines. The product images shown are for illustration purposes only and may not be an exact representation of the final product. All information is subject to change without notice.

PEAK HORSEPOWER
Fuel	HP	KW	RPM
Gasoline	34.1	25.4	3600
LPG	34.1	25.4	3600
PEAK TORQUE
Fuel	FT-LBS	N-M	RPM
Gasoline	50.0	67.8	3060
LPG	50.0	67.8	3060

1) Mobile Fuel options: Gasoline, LPG

2) Fuel and emission control system that meets Tier II

EPA/CARB emission regulations for SSI engines

3) Closed-loop, port-injected EFI

4) Liquid-cooled

5) 70-amp alternator

6) Hydraulic pump housing

DIMENSIONS	IN	MM
Length	22.91	581.9
Width	17.10	434.3
Height	26.68	677.7
