13 Liter
Power Systems
| PRODUCT SPECIFICATIONS | |
| Model Number | 13L |
|---|---|
| Cylinders | I-6 |
| Combustion System | Spark-ignited |
| Cooling System | Water-cooled |
| Displacement | 765 cid (12,500 cc) |
| Compression Ratio | 9.75:1 |
| Bore & Stroke | 5.00 in x 6.50 in (127 mm x 165 mm) |
| Fuel Type | NATURAL GAS (NG), PROPANE (LP) |
| Direction of rotation | Counter-clockwise viewed on flywheel |
SAE J1995 rated following 56100020 PSI Derate Specification with a tolerance of +/-5%. Power and torque values are based on standard assumptions. kWe values are based on standard assumptions for mechanical and electrical losses. Ratings and performance are solely for reference only and subject to site conditions and PSI application and ratings guidelines. The product images shown are for illustration purposes only and may not be an exact representation of the final product. All information is subject to change without notice.
POWER RATINGS
GENERAL DATA & FEATURES
DIMENSIONS
| 50 HZ (1500 RPM) | ||||
| Rating | Fuel | kWe | kWm | bHp |
|---|---|---|---|---|
| Standby | NG | 220 | 250 | __ |
| Standby | LP | 132 | 150 | __ |
| Prime | NG | 142 | 161 | __ |
| Prime | LP | 92 | 105 | __ |
| LTP | NG | 202 | 230 | __ |
| LTP | LP | 132 | 180 | __ |
| 60 HZ (1800 RPM) | ||||
| Rating | Fuel | kWe | kWm | bHp |
|---|---|---|---|---|
| Standby | NG | 262 | 300 | 402 |
| Standby | LP | 150 | 181 | 243 |
| Prime | NG | 207 | 245 | 329 |
| Prime | LP | 150 | 181 | 243 |
| LTP | NG | 202 | 230 | __ |
| LTP | LP | 132 | 180 | __ |
